Jazzy Wheelchair Motor For Sale
What is a Jazzy Wheelchair Motor?
A Jazzy wheelchair motor refers to the motors used in Jazzy power wheelchairs, a popular line of electric wheelchairs produced by Pride Mobility Products Corporation. These wheelchairs are designed to provide mobility and independence for individuals with limited mobility. The motors in Jazzy wheelchairs are essential components that enable movement and control.
Features of Jazzy Wheelchair Motors
High Performance:
Jazzy wheelchair motors are designed for reliability and performance, ensuring smooth and efficient operation over various terrains.
Durability:
Built to withstand daily use, Jazzy motors are robust and durable, providing long-lasting service with minimal maintenance.
Variable Speed Control:
Equipped with advanced motor controllers, Jazzy motors offer variable speed settings, allowing users to adjust the speed according to their comfort and needs.
Precision Control:
The motors work in conjunction with sophisticated joystick controls, providing precise maneuverability and control.
High Torque:
Jazzy motors deliver high torque, essential for climbing slopes, navigating obstacles, and handling different types of surfaces.
Battery Efficiency:
Designed for optimal battery efficiency, ensuring extended usage between charges.
Application Areas
Indoor Use: Compact models with tight turning radii for navigating indoor spaces like homes, offices, and shopping centers.
Outdoor Use: Models with larger wheels and higher ground clearance for outdoor activities and uneven terrain.
Heavy-Duty Use: Models designed for users who require higher weight capacity and enhanced stability.
Popular Jazzy Wheelchair Models
Jazzy Select Series:
Known for their ease of use and reliable performance, suitable for both indoor and outdoor use.
Jazzy Elite Series:
Featuring robust construction and advanced suspension for enhanced outdoor performance.
Jazzy Air Series:
Equipped with adjustable seat height for greater accessibility and convenience in various settings.
Jazzy 600 Series:
Offering superior performance with Mid-Wheel 6® technology for maximum stability and maneuverability.
Purchasing and Manuals
When purchasing a Jazzy wheelchair, it typically includes a user manual that provides detailed information about the motor, wiring diagrams, maintenance instructions, and troubleshooting tips.
For more specific information about Jazzy wheelchair motors or to download manuals, you can visit the Pride Mobility Products website.
What are the Jazzy Wheelchair Motor specs ?
The specifications of Jazzy wheelchair motors can vary depending on the specific model of the wheelchair. However, here are some general specifications and features that are common across many Jazzy wheelchair motors:
General Specifications
Motor Type:
High-torque, DC motors (usually brushed DC motors).
Voltage:
Typically 24 volts, powered by two 12-volt batteries connected in series.
Power Output:
Varies by model, but generally ranges from 300 to 450 watts per motor.
Speed:
Maximum speeds typically range from 4 mph (6.4 km/h) to 6 mph (9.7 km/h), depending on the model and user weight.
Torque:
High torque motors designed to handle various terrains and slopes (exact torque values vary by model).
Drive System:
Mid-wheel drive for tight turning radius and excellent maneuverability.
Some models offer front-wheel or rear-wheel drive options.
Suspension:
Advanced suspension systems in some models to provide a smoother ride over uneven terrain.
Weight Capacity:
Varies by model, typically ranging from 300 lbs (136 kg) to 450 lbs (204 kg).
Specific Models and Their Motor Specs
Jazzy Select Series
Motor Power: Approximately 300 watts per motor.
Max Speed: Up to 4 mph (6.4 km/h).
Drive System: Mid-wheel drive.
Weight Capacity: Up to 300 lbs (136 kg).
Jazzy Elite Series
Motor Power: Approximately 350 watts per motor.
Max Speed: Up to 4.5 mph (7.2 km/h).
Drive System: Rear-wheel drive.
Weight Capacity: Up to 300 lbs (136 kg).
Jazzy Air Series
Motor Power: Approximately 350 watts per motor.
Max Speed: Up to 4 mph (6.4 km/h).
Drive System: Mid-wheel drive.
Weight Capacity: Up to 300 lbs (136 kg).
Additional Feature: Adjustable seat height.
Jazzy 600 Series
Motor Power: Approximately 450 watts per motor.
Max Speed: Up to 4 mph (6.4 km/h).
Drive System: Mid-wheel drive with Mid-Wheel 6® technology.
Weight Capacity: Up to 300 lbs (136 kg).
Battery and Charging
Battery Type: Sealed lead-acid (SLA) or gel batteries.
Battery Range: Typically 10 to 15 miles (16 to 24 km) on a full charge, depending on terrain, user weight, and battery condition.
Charger: Off-board charger with varying charge times depending on battery capacity.
Manuals and Additional Information
For detailed specifications, wiring diagrams, and maintenance instructions, it is recommended to consult the specific user manual for your Jazzy wheelchair model. You can find these manuals on the Pride Mobility Products website. Select your model from the product listings to access the corresponding manual and other resources.
Jazzy Wheelchair Motor Alternatives – JIECANG
If you are considering alternatives to Jazzy wheelchair motors, JIECANG offers a range of high-quality wheelchair motors that are worth exploring. JIECANG motors are known for their reliability, efficiency, and advanced features.
By choosing JIECANG wheelchair motors, you can benefit from advanced technology, reliability, and customizable options to meet your specific mobility needs. Whether you are looking for an indoor, outdoor, or heavy-duty solution, JIECANG has a range of products to consider.
For more information about wheelchair motor, please visit our official website https://www.jiecang.com/
